Mourad Metals is a reliable manufacturer and supplier of top-notch Beryllium Chromium Copper bars and rods, proudly based in Tunis, Tunisia. With a keen emphasis on precision metallurgy and unwavering quality, the company provides copper alloy products that align with international standards and meet the rigorous demands of various industries. Mourad Metals skillfully blends cutting-edge production methods with stringent quality control to guarantee outstanding dimensional accuracy, surface finish, and overall performance. Catering to a wide range of industries both locally and globally, the company is dedicated to being dependable, ensuring timely deliveries, and offering tailored solutions for applications that require exceptional strength, conductivity, and durability.
Beryllium Chromium Copper bars and rods are mainly made from copper mixed with specific amounts of beryllium and chromium, which boosts their strength and thermal stability. The beryllium content typically falls between 0.4% and 2%, while chromium enhances hardness and helps resist softening at higher temperatures. These alloys are known for their impressive tensile strength, good fatigue resistance, and excellent wear characteristics, all while maintaining solid electrical and thermal conductivity. They also resist corrosion well and can be heat-treated to achieve a broad spectrum of mechanical properties.
Standard & Material | CDA 110 ETP, ASTM B124, ASTM B152, ASTM B187, ASTM B188, ASTM B272 |
HOLLOW RODS | Min Bore Size 20 mm and Max OD 100 mm |
ROUND RODS | 8mm To 100 mm |
HEX | 10mm To 60mm |
SQUARE | 10mm To 60mm |
FLAT | 10mm Min Thickness and max Width 120mm |
BILLETS | Up to 200 mm |
INGOTS | As per Specification |
|
Cu |
O |
|
|
Min/Max |
99.90 min |
|
|
Nominals |
– |
0.04 |
Product Property | US Customary | Metric |
Coefficient of Thermal Expansion | 9.4 · 10 6? per °F (68-212 F) | 16.9 · 10 6? per °C (20-100 C) |
Coefficient of Thermal Expansion | 9.6 · 10 6? per °F (68-392 F) | 17.3 · 10 6? per °C (20-200 C) |
Coefficient of Thermal Expansion | 9.8 · 10 6? per °F (68-572 F) | 17.6 · 10 6? per °C (20-300 C) |
Density | 0.322 lb/in3 @ 68 F | 8.91 gm/cm3 @ 20 C |
Electrical Conductivity | 101%IACS @ 68 F | 0.591 MegaSiemens/cm @ 20 C |
Electrical Resistivity | 10.3 ohms-cmil/ft @ 68 F | 1.71 microhm-cm @ 20 C |
Melting Point Liquid US | 1981 F | 1083 C |
Melting Point Solid US | 1949 F | 1065 C |
Modulas of Elasticity in Tension | 17000 ksi | 117000 MPa |
Modulas of Rigidity | 6400 ksi | 44130 MPa |
Specific Gravity | 8.91 | 8.91 |
Specific Heat Capacity | 0.092 Btu/lb/ °F at 68 F | 393.5 J/kg · °K at 293 K |
Thermal Conductivity | 226.0 Btu · ft/(hr · Ft2 · °F) at 68 F | 391.1W/m · °K at 20 C |
End Product | Specification |
Bar | ASME SB133, ASTM B152, SAE J461, J463 |
Bar, Bus | ASTM B187 |
Bar, Forging | ASTM B124 |
Rod | ASME SB133, MILITARY MIL-C-12166, SAE J461, J463 |
Rod, Bus | ASTM B187 |
Yes, Beryllium Chromium Copper bars and rods can be used at high temperatures due to their excellent thermal conductivity, strength, and stability.
Choose the right Beryllium Chromium Copper bars by considering application needs, grade, temperature tolerance, dimensions, corrosion resistance, and supplier quality.
Yes, Beryllium Chromium Copper bars are recyclable and retain their properties effectively after recycling.
These Beryllium Chromium Copper bars and rods find their way into various applications that demand a blend of high strength, conductivity, and resistance to wear and heat. You’ll often see them in electrical connectors, switch components, welding electrodes, and parts for resistance welding. They’re also utilized in molds, dies, springs, and precision mechanical components across the automotive, aerospace, and electronics sectors. Their non-sparking quality makes them ideal for hazardous environments, and their durability ensures they perform reliably even in the toughest operational conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
