Mourad Metals, located in Tunis, Tunisia, stands out as a top manufacturer and supplier of high-quality Hastelloy C22 Bars and Rods. The company focuses on crafting precision-engineered metal products that adhere to international standards, catering to a diverse array of industrial applications. By employing cutting-edge manufacturing techniques and rigorous quality control measures, Mourad Metals guarantees that every bar and rod offers consistent strength, durability, and remarkable corrosion resistance. With a strong dedication to timely deliveries, technical know-how, and customer satisfaction, the company has built a solid reputation as a reliable partner for engineers, fabricators, and industrial clients in need of dependable Hastelloy C22 solutions for challenging and corrosive environments.
Hastelloy C22 Bars and Rods are primarily made of nickel, enriched with notable amounts of chromium, molybdenum, and tungsten, along with trace elements of iron, cobalt, and manganese. This thoughtfully balanced composition results in exceptional mechanical properties, such as high tensile and yield strength, along with excellent ductility and toughness at elevated temperatures. The alloy showcases outstanding resistance to pitting, stress corrosion cracking, and both oxidizing and reducing chemicals. Thanks to its thermal stability and chemical resilience, Hastelloy C22 Bars and Rods are perfect for applications that demand both strength and long-lasting corrosion protection in harsh industrial settings.
| Standard | ASTM B574, ASME SB574 |
| Round Bar Size | 3mm~ 800mm |
| Square Bar Size | 4mm* 4mm ~100mm* 100mm |
| Flat Bar Size | 2mm ~ 100mm |
| Hex Bar Size | 2mm ~ 100mm |
| Angle Size | 3mm* 20mm* 20mm~ 12mm* 100mm* 100mm |
| Thickness | 50 mm to 6000 mm Long |
| Length | 1 To 6 Meters, Custom Cut Length |
| Form | Round, Square, Hex(A/F), Rectangle, Billet, Ingot, Forging Etc |
| Grade | Ni | C | Cr | Co | Fe | Mn | Mo | P | Si | S | W | V |
| Hastelloy C22 | Bal | 0.010 max | 20 – 22.5 | 2.5 max | 2 – 6 | 0.50 max | 12.5 – 14.5 | 0.02 max | 0.08 max | 0.02 max | 2.5 – 3.5 | 0.35 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.69 g/cm3 | 1399 °C (2550 °F) | Psi – 1,00,000 , MPa – 690 | Psi – 45000 , MPa – 310 | 45 % |
| STANDARD | WERKSTOFF NR. | UNS | GOST | AFNOR | JIS | OR | EN |
| Hastelloy C22 | 2.4602 | N06022 | – | – | NW 6022 | – | NiCr21Mo14W |
| ALLOY C-22 (Ni/22Cr/13Mo/3Fe/3W) / INCONEL 622/C-22 Round Bar | Dimension |
|---|---|
| cold drawn, solution annealed | Dia=16.0 mm, Weight=1.75 kg/m |
| hot worked, solution annealed, peeled | Dia=20.0 mm, Weight=2.6 kg/m |
| hot worked, solution annealed, peeled | Dia=25.4 mm, Weight=4.5 kg/m |
| hot worked, solution annealed, peeled | Dia=30.0 mm, Weight=6.14 kg/m |
| hot worked, sol annealed, peeled | Dia=38.1 mm, Weight=10.1 kg/m |
| extruded, machined, solution annealed | Dia=45.0 mm, Weight=13.15 kg/m |
| hot worked, solution annealed, peeled | Dia=50.8 mm, Weight=18.0 kg/m |
| extruded, machined, solution annealed | Dia=70.0 mm, Weight=35.0 kg/m |
| solution annealed, peeled | Dia=82.55 mm, Weight=47.6 kg/m |
| hot worked, solution annealed, peeled | Dia=101.6 mm, Weight=72.1 kg/m |
| forged, solution annealed, peeled | Dia=115.0 mm, Weight=89.4 kg/m |
| forged, solution annealed, peeled | Dia=130.0 mm, Weight=113.9 kg/m |
| forged, solution annealed, peeled | Dia=150.0 mm, Weight=152.15 kg/m |
| forged, turned | Dia=165.1 mm, Weight=187 kg/m |
Yes, Hastelloy C22 Bars are highly corrosion-resistant, particularly against pitting, crevice corrosion, and stress corrosion cracking in harsh environments. They excel in resisting acids, oxidizing agents, and chloride-induced corrosion.
Yes, Hastelloy C22 rods can be customized in size and length to meet specific industrial requirements. Manufacturers often offer tailored dimensions to suit diverse applications.
Hastelloy C22 bars perform exceptionally well in high-temperature environments due to their superior resistance to oxidation and thermal stability. They maintain strength and corrosion resistance under extreme conditions.
These bars and rods find extensive use in the chemical processing, pharmaceutical, marine, aerospace, and petrochemical industries, thanks to their superior corrosion resistance and mechanical durability. They are particularly well-suited for manufacturing pumps, valves, heat exchangers, piping systems, reactor vessels, and other components that face aggressive chemicals or high-temperature conditions. Moreover, these Hastelloy C22 Bars and Rods are utilized in seawater systems, pollution control equipment, and other demanding applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
