Mourad Metals stands out as a top-notch manufacturer and supplier located in Tunis, Tunisia, focusing on high-performance nickel-iron-chromium alloys tailored for tough industrial needs. They provide Incoloy 825 Forgings, crafted to meet exact specifications and adhere to international standards. With state-of-the-art production facilities, rigorous quality control, and knowledgeable technical support, Mourad Metals caters to various sectors, including chemical processing, petrochemical, power generation, marine, and offshore engineering. Their dedication to reliability, quality, and prompt delivery has earned them a reputation as a trusted partner for clients both regionally and globally.
Incoloy 825 is a nickel-iron-chromium alloy enriched with molybdenum, copper, and titanium, specifically engineered for outstanding corrosion resistance in both oxidizing and reducing environments. This alloy boasts impressive mechanical properties, such as high tensile and yield strength, good toughness, and dependable performance across a broad temperature range. Incoloy 825 Forgings also show remarkable resistance to pitting, crevice corrosion, and stress corrosion cracking, especially in acidic and chloride-rich environments.
Specifications ASTM B564 / ASME SB564
Flat bar blocks up to 27″ width and 15,000 lbs.
Cylinders and sleeves up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts up to 144″ maximum length and 20,000 lbs.
| Grade | C | Mn | Si | S | Al | Ti | Fe | Ni | Cr |
| Incoloy 825 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | 0.40 max | 0.40 max | 5.0 max | 58.0 min | 20.0 – 23.0 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa -930 | Psi – 75,000 , MPa – 517 | 42.5 % |
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | BS | GOST | OR |
| Alloy 825 | N08825 | 2.4858 | NC22DNB4M | NiCr22Mo9Nb | NCF 825 | NA 21 | ЭП703 | ЭИ602 |
To determine if Incoloy 825 Forgings meet your needs, assess your application's requirements for corrosion resistance, strength, and temperature tolerance. Consult product specifications and industry standards to ensure compatibility with your operational environment.
The forging process for Incoloy 825 typically takes several hours to days, depending on the size, complexity, and specific requirements of the component. Additional time may be needed for heat treatment and quality inspections.
Yes, Incoloy 825 can be forged into custom shapes due to its excellent workability and adaptability. Skilled forging techniques and precise tooling ensure it meets specific design and application requirements.
Incoloy 825 Forgings find extensive use in settings that demand exceptional corrosion resistance and mechanical strength. They’re often utilized in chemical processing equipment, heat exchangers, pressure vessels, valves, and piping systems. Additionally, this alloy is crucial in marine, offshore, and power generation applications where resistance to strong acids, seawater, and harsh chemical conditions is essential. Thanks to its blend of durability, corrosion resistance, and high strength, Incoloy 825 is perfectly suited for challenging industrial and chemical applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Mourad Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Tunis, Tunisia
