Mourad Metals, located in Tunis, Tunisia, is a reputable manufacturer and supplier of top-notch nickel-copper alloys, including Monel Bright Bars. Renowned for their precision, outstanding surface finish, and exact dimensions, Mourad Metals crafts bright bars that adhere to strict industrial standards. Designed for tough applications, these bars are perfect for industries like marine, chemical processing, petrochemical, and aerospace. With a strong emphasis on corrosion resistance, durability, and long-lasting reliability, Mourad Metals guarantees that its Monel Bright Bars consistently perform well in challenging and aggressive environments.
Monel Bright Bars are nickel-copper alloys that boast remarkable resistance to corrosion from seawater, acids, alkalis, and various chemical media. On the mechanical side, they provide good tensile strength, toughness, and moderate ductility, making them ideal for components that need both strength and corrosion resistance. Their bright finish not only ensures a high-quality surface but also offers precise dimensions and easy machining, which cuts down on the need for additional processing.
| Specifications | : | ASTM B164 / ASTM SB164 |
| Dimensions | : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Size | : | 5 mm To 500 mm |
| Diameter | : | 0.1 mm to 100 mm |
| Length | : | 100 mm To 3000 mm Long & Above |
| Finish | : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Tolerance | : | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Form | : | Bright |
| Designation | C% | Co% | Cr% | Mo% | Ni% | V% | W% | Ai% | Cu% | Nb/Cb Ta% | Ti% | Fe% | Sonstige Autres-Other % |
| – | 0.12 | – | – | – | 65.0 | – | – | – | 32.0 | – | – | 1.5 | Mn 1.0 |
| – | 0.10 | – | – | – | 43.0 | – | – | – | 53.0 | – | – | 0.75 | Si 0.25; Mn 2.25 |
| – | 0.15 | – | Â | Â | 52.0-57.0 | – | – | 0.05 | rest/bal | – | – | 0.50 | Mn 0.10; Si 0.10;S o.024 |
| – | 0.10 | – | – | – | 63.0-17.0 | – | – | 2.5-3.5 | rest/bal | – | 0.50 | 2.0 | Mn 1.5;Si 0.5; S 0.010 |
| – | 0.13 | – | – | – | 64.0 | – | – | 2.8 | 30.0 | – | 0.6 | 1.0 | Mn 0.8 |
| – | 0.15 | – | – | – | 66.0 | – | – | – | 31.0 | – | – | 1.2 | Mn 1.0; S 0.04 |
| Element | Monel |
| Density | 8.8 g/cm3 |
| Melting Point | 1350 °C (2460 °F) |
| Tensile Strength | Psi – 80,000 , MPa – 550 |
| Yield Strength (0.2%Offset) | Psi – 35,000 , MPa – 240 |
| Elongation | 40 % |
| Size | kilogram / Meter | kilogram / Foot | Size | kilogram / Meter | kilogram / Foot | Size | kilogram / Meter | kilogram / Foot |
|---|---|---|---|---|---|---|---|---|
| 1/8″ | 0.062 | 0.019 | 22 millimeter | 2.979 | 0.908 | 3 to 1/4″ | 41.996 | 12.800 |
| 3 millimeter | 0.055 | 0.017 | 20 millimeter | 2.470 | 0.753 | 3″ | 35.762 | 10.900 |
| 4 millimeter | 0.098 | 0.030 | 24 millimeter | 3.543 | 1.080 | 3 to 3/4″ | 55.780 | 17.001 |
| 5/32″ | 0.095 | 0.029 | 7/8″ | 3.038 | 0.926 | 3 to 1/2″ | 48.772 | 14.850 |
| 5 millimeter | 0.154 | 0.047 | 1″ | 3.970 | 1.210 | 4 to 1/4″ | 72.249 | 21.908 |
| 3/16″ | 0.141 | 0.043 | 25 millimeter | 3.871 | 1.180 | 4″ | 63.340 | 19.306 |
| 6 millimeter | 0.223 | 0.068 | 27 millimeter | 4.490 | 1.368 | 4 to 3/4″ | 90.249 | 27.366 |
| 7/32″ | 0.190 | 0.058 | 26 millimeter | 4.170 | 1.271 | 4 to 1/2″ | 80.340 | 24.4487 |
| 7 millimeter | 0.298 | 0.091 | 30 millimeter | 5.548 | 1.691 | 5 to 1/2″ | 121.000 | 36.690 |
| 1/4″ | 0.249 | 0.076 | 1 to 1/8″ | 5.033 | 1.534 | 5″ | 99.940 | 30.461 |
| 8 millimeter | 0.398 | 0.120 | 32 millimeter | 6.314 | 1.894 | 6 to 1/2″ | 167.630 | 51.093 |
| 5/16″ | 0.387 | 0.118 | 1 to 1/4″ | 6.349 | 1.924 | 6″ | 143.900 | 43.860 |
| 3/8″ | 0.557 | 0.170 | 35 millimeter | 7.553 | 2.390 | 7 to 1/2″ | 225.000 | 68.226 |
| 9 millimeter | 0.498 | 0.152 | 1 to 3/8″ | 7.550 | 2.303 | 7″ | 196.000 | 59.432 |
| 11 millimeter | 0.748 | 0.228 | 38 millimeter | 8.903 | 2.792 | 10″ | 397.140 | 121.048 |
| 10 millimeter | 0.620 | 0.189 | 36 millimeter | 7.999 | 2.438 | 8″ | 254.55 | 77.586 |
| 12 millimeter | 0.889 | 0.271 | 40 millimeter | 9.872 | 3.009 | Â | Â | Â |
| 7/16″ | 0.761 | 0.232 | 1 to 1/2″ | 8.951 | 2.715 | Â | Â | Â |
| 13 millimeter | 1.043 | 0.318 | 1 to 3/4″ | 12.179 | 3.712 | Â | Â | Â |
| 1/2″ | 0.994 | 0.303 | 1 to 5/8″ | 10.449 | 3.200 | Â | Â | Â |
| 9/16″ | 1.256 | 0.383 | 1 to 7/8″ | 13.977 | 4.260 | Â | Â | Â |
| 14 millimeter | 1.207 | 0.368 | 45 millimeter | 12.555 | 3.807 | Â | Â | Â |
| 5/8″ | 1.551 | 0.473 | 50 millimeter | 15.414 | 4.698 | Â | Â | Â |
| 15 millimeter | 1.391 | 0.424 | 48 millimeter | 14.205 | 4.330 | Â | Â | Â |
| 17 millimeter | 1.791 | 0.543 | 2 to 1/8″ | 17.963 | 5.475 | Â | Â | Â |
| 16 millimeter | 1.578 | 0.481 | 2″ | 15.906 | 4.848 | Â | Â | Â |
| 18 millimeter | 2.001 | 0.610 | 60 millimeter | 22.205 | 6.768 | Â | Â | Â |
| 11/16″ | 1.880 | 0.573 | 2 to 1/4″ | 20.128 | 6.135 | Â | Â | Â |
| 3/4″ | 2.237 | 0.682 | 2 to 3/8″ | 22.435 | 6.838 | Â | Â | Â |
| Â | Â | Â | 2 to 1/2″ | 24.856 | 7.576 | Â | Â | Â |
| Â | Â | Â | 2 to 5/8″ | 27.409 | 8.354 | Â | Â | Â |
| Â | Â | Â | 2 to 3/4″ | 30.083 | 9.169 | Â | Â | Â |
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@mouradmetals.com
Yes, Monel Bright Bars can be heat treated to enhance their mechanical properties, such as strength and hardness. However, care must be taken to avoid excessive heat, which could affect their corrosion resistance.
When installing Monel Bright Bars, ensure proper handling to avoid mechanical damage and stress concentrations. Additionally, consider material compatibility, environmental conditions, and temperature variations to optimize performance and longevity.
These Monel Bright Bars find extensive use in manufacturing fasteners, shafts, valves, pumps, marine hardware, and precision components for chemical, petrochemical, and offshore applications. Their exceptional corrosion resistance and mechanical properties guarantee a long service life, low maintenance, and dependable operation even in harsh conditions. Engineers trust Monel Bright Bars for creating robust, high-performance components that can endure aggressive chemical, marine, and industrial environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
