Mourad Metals is a reputable manufacturer and supplier of Stainless Steel 316L Bars and Rods, proudly based in Tunis, Tunisia. They deliver top-notch products to a variety of industrial sectors. With a keen emphasis on precision manufacturing, consistent quality, and adherence to international standards, Mourad Metals guarantees exceptional corrosion resistance, durability, and performance in every bar and rod they provide. The Stainless Steel 316L Bars and Rods from Mourad Metals are crafted using cutting-edge technology and rigorous quality control measures, making them perfect for even the most demanding environments. The company is dedicated to reliability, timely delivery, and tailored solutions to meet the unique needs of clients across global markets.
These Stainless Steel 316L Bars and Rods are primarily made of iron, containing about 16–18% chromium, 10–14% nickel, and 2–3% molybdenum, along with a low carbon content of up to 0.03%. This low carbon level significantly boosts resistance to intergranular corrosion, especially after welding. On the mechanical side, SS 316L boasts impressive tensile strength, good yield strength, and high ductility and toughness. It also shows remarkable resistance to pitting, crevice corrosion, and chemical attacks, particularly in environments rich in chlorides and marine conditions.
| Specification | ASTM A276/ A479, ASME SA276/SA479 |
|---|---|
| Grade | Stainless Steel 316L (UNS S31603) |
| Flat bar size | 1/2” to 10” in thickness range of 2mm to 150mm |
| Square bar size | 18mm – 47mm (11/16″ to 1-3/4″) |
| Round bar size | Outside Diameter in the range of 4mm to 500mm |
| Hex Bar size | 18mm – 57mm (11/16″ to 2-3/4″) |
| Bright Bar | Outside Diameter in the range of 4mm to 100mm |
| Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Billet Size | 1/2″ to 495mm Diameter |
| Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Rectangular bar Size | 33 x 30mm to 295 x 1066mm |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Surface | Cold Drawn, Bright, Sand Blasting Finished, Hot Rolled Pickled, Hairline, Polished |
| Condition | Hardened & tempered, annealed |
| Technique | 316L Stainless Steel Cold Drawn, Hot Rolled, Forged Round Bar, Rod, Cold Rolled |
| Processing | Bar cutting to 650mm |
| Section | 3.0 to 12.0mm thickness |
| Form | Precision Ground Bar, Flat Bar, Square, Round, Half Round Bar, Rod, Rectangle, Hex (A/F), T-Bar, Channel Bar,Blocks, Round Rod, Threaded, Profiles, Billet, Ingot, I/H Bar, Forging, Rings, Hollow, Triangle etc. |
| Our 316L Stainless Steel Round bar conforms to NACE MR0175/ISO 15156 | |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 316L | 0.3 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 16 – 18 | 2 – 3 | 10 – 14 | 0.10 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1454 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 40 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316L | 1.4404 / 1.4435 | S31603 | SUS 316L | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 | Z3CND17‐11‐02 / Z3CND18‐14‐032 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
Stainless Steel 316L contains molybdenum, which enhances resistance to chloride-induced pitting and corrosion, making it highly suitable for marine and coastal applications.
Yes, the low carbon content in 316L minimizes carbide precipitation during welding, ensuring excellent corrosion resistance even in heat-affected zones.
Stainless Steel 316L Bars and Rods find extensive use in industries that demand high corrosion resistance and strict hygiene standards. You’ll commonly see them in chemical processing equipment, marine components, pharmaceutical machinery, food and beverage processing systems, and heat exchangers. They’re also widely utilized in oil and gas, petrochemical plants, medical devices, and architectural structures that face harsh conditions. Thanks to their excellent weldability and formability, SS 316L bars and rods are the go-to choice for fabrication, machining, and structural applications where long service life and reliability are crucial.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Mourad Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Tunis, Tunisia
