Mourad Metals, located in Tunis, Tunisia, stands out as a top-notch manufacturer and supplier of premium stainless steel products, with a special focus on STAINLESS STEEL 416 FLAT BARS. Known for their precision engineering and reliable performance, Mourad Metals ensures that their products adhere to strict international standards. The 416 flat bars are made from high-quality raw materials and cutting-edge production methods, guaranteeing exceptional strength, corrosion resistance, and machinability. Catering to industries that prioritize reliability and durability, Mourad Metals is dedicated to offering customized solutions, prompt deliveries, and outstanding customer service, making them a trusted partner for stainless steel supplies throughout Tunisia and beyond.
STAINLESS STEEL 416 FLAT BARS are a type of martensitic stainless steel that features a high sulfur content, enhancing their machinability. Typically, they consist of 12–14% chromium, 0.15% carbon, 0.75% manganese, and 0.03% phosphorus. This specific blend provides moderate corrosion resistance, impressive hardness, and high strength. Their mechanical properties include a tensile strength ranging from 655 to 825 MPa, yield strength between 415 and 550 MPa, and an elongation of 15 to 20%. With a Brinell hardness between 187 and 235 HB, 416 stainless steel flat bars are perfect for precision-machined components while also resisting wear and moderate corrosion in mild environments.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A582, A276, A564, ASTM A484, 484M
Surface : hrap, hot rolled pickled or sand blasting finished, cold drawn, polished, hairline
Range : Range – 3.17mm to 350mm dia
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 416 | 0.15 | 14.0 – 12.0 | 1.25 | – | 0.06 | 0.15 | 1 |
| Element | Density, lb/in3 | Melting Point | Electrical Resistivity |
| SS 416 | 0.282 lbs/in3 7 .80 g/cm3 | 2700 – 2790 °F (1488 – 1530 °C) | At 70 °F (21 °C): 343.0 |
| Flat Bar | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.49 | 1.60 |
| 18 | 0.62 | 2.02 |
| 20 | 0.76 | 2.49 |
| 22 | 0.92 | 3.02 |
| 25 | 1.19 | 3.90 |
| 28 | 1.49 | 4.89 |
| 28 | 1.49 | 4.89 |
| 30 | 1.71 | 5.61 |
| 32 | 1.95 | 6.38 |
| 36 | 2.46 | 8.08 |
| 38 | 2.74 | 9.00 |
| 40 | 3.04 | 9.97 |
| 45 | 3.85 | 12.62 |
| 50 | 4.75 | 12.62 |
| 56 | 8.96 | 19.55 |
| 60 | 6.84 | 22.44 |
| 65 | 8.03 | 26.34 |
| 70 | 9.31 | 30.54 |
| 75 | 10.69 | 35.06 |
| 80 | 12.16 | 39.89 |
| 90 | 15.39 | 50.49 |
| 100 | 19 | 62.34 |
Stainless Steel 416 Flat Bar is commonly used in applications requiring moderate corrosion resistance, high strength, and machinability. It's used in shafts, valves, pumps, fasteners, and machinery components, particularly in the automotive, aerospace, and manufacturing industries.
The typical hardness level of Stainless Steel 416 Flat Bar ranges from 30 to 40 HRC (Rockwell Hardness Scale). The hardness can vary depending on the heat treatment process, with higher hardness achieved through quenching and tempering.
Common methods for machining Stainless Steel 416 Flat Bar include turning, milling, drilling, and grinding. Due to its high machinability, it can be easily processed using conventional tools, though cutting speeds and coolant usage should be optimized to reduce heat buildup.
STAINLESS STEEL 416 FLAT BARS find extensive use in industries that demand high machinability and moderate corrosion resistance. They are particularly well-suited for crafting shafts, gears, fasteners, valve components, and pump parts where precision machining is crucial. Moreover, these flat bars are utilized in automotive, chemical, and food processing equipment, as well as in decorative hardware that benefits from a polished finish. Their unique combination of strength, hardness, and ease of fabrication makes them ideal for both functional and aesthetic applications. Mourad Metals provides 416 flat bars customized to meet industrial specifications, ensuring quality and performance in every order.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
