Mourad Metals, located in Tunis, Tunisia, has built a solid reputation as a reliable manufacturer and supplier of top-notch Carbon Steel Spring Bars and Rods. The company takes pride in crafting precision-engineered products that adhere to international standards, catering to a wide range of industrial needs. By employing cutting-edge manufacturing techniques and rigorous quality control measures, Mourad Metals guarantees that each bar and rod offers consistent strength, durability, and dependable performance. With a strong commitment to timely deliveries, technical know-how, and customer satisfaction, they have become a trusted partner for engineers, fabricators, and industrial clients in search of robust Carbon Steel Spring Bars and Rods for mechanical, automotive, and industrial applications.
These Carbon Steel Spring Bars and Rods are primarily made from iron, with carefully controlled amounts of carbon and trace elements that boost their strength, hardness, and wear resistance. This unique composition results in outstanding mechanical properties, such as high tensile strength, elasticity, toughness, and fatigue resistance. Designed to endure repeated stress and deformation while retaining their shape, these bars and rods are perfect for spring and load-bearing applications. Their durability and resilience ensure they perform reliably even in high-stress and high-cycling conditions, making them suitable for harsh industrial environments.
|
Steel Grade |
C |
Mn |
Si |
P |
S |
Cr |
Ni |
B |
Cu |
Mo |
V |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
55 |
0.52-0.60 |
0.50-0.80 |
0.17-0.37 |
0.035 max |
0.035 max |
0.25 max |
0.30 max |
/ |
0.25 max |
/ |
/ |
|
65 |
0.62-0.70 |
0.50-0.80 |
0.17-0.37 |
0.035 max |
0.035 max |
0.25 max |
0.25 max |
/ |
0.25 max |
/ |
/ |
|
70 |
0.62-0.75 |
0.50-0.80 |
0.17-0.37 |
0.035 max |
0.035 max |
0.25 max |
0.25 max |
/ |
0.25 max |
/ |
/ |
|
75 |
0.72-0.80 |
0.50-0.80 |
0.17-0.37 |
0.035 max |
0.035 max |
0.25 max |
0.30 max |
/ |
0.25 max |
/ |
/ |
|
85 |
0.95-1.04 |
0.40 max |
0.35 max |
0.025 max |
0.025 max |
/ |
/ |
/ |
/ |
/ |
/ |
|
65Mn |
0.62-0.70 |
0.90-1.20 |
0.17-0.37 |
0.035 max |
0.035 max |
0.25 max |
0.25 max |
/ |
0.25 max |
/ |
/ |
|
60Si2Mn |
0.56-0.64 |
0.70-1.00 |
1.50-2.00 |
0.035 max |
0.035 max |
0.35 max |
0.25 max |
/ |
0.25 max |
/ |
/ |
|
50CrVA |
0.46-0.54 |
0.50-0.80 |
0.17-0.37 |
0.025 max |
0.025 max |
0.80-1.10 |
0.35 max |
/ |
0.25 max |
/ |
0.10-0.20 |
|
55SiCrA |
0.51-0.59 |
0.50-0.80 |
1.20-1.60 |
0.025 max |
0.025 max |
0.50-0.80 |
0.35 max |
/ |
0.25 max |
/ |
/ |
|
60Si2CrA |
0.56-0.64 |
0.40-0.70 |
1.40-1.80 |
0.025 max |
0.025 max |
0.70-1.00 |
0.35 max |
/ |
0.25 max |
/ |
/ |
|
Steel Grade |
Tensile Strength Rm (Mpa) |
Yield Strength Rp0.2 (Mpa) |
Elongation A5 (%) |
Area Reduction Ratio C (%) |
|---|---|---|---|---|
|
65 |
980 min |
785 min |
9 min |
35 min |
|
70 |
1030 min |
835 min |
8 min |
30 min |
|
85 |
1130 min |
980 min |
6 min |
30 min |
|
65Mn |
980 min |
785 min |
8 min |
30 min |
|
60Si2Mn |
1275 min |
1180 min |
5 min |
25 min |
|
50CrVA |
1275 min |
1130 min |
10 min |
40 min |
|
55SiCrA |
1450-1750 |
1300 min |
6 min |
25 min |
|
60Si2CrA |
1765 min |
1570 min |
6 min |
20 min |
When selecting carbon steel spring bars, consider factors like the required strength, durability, and fatigue resistance for the specific application. Also, evaluate the environment's corrosion potential and the bar's ability to retain spring properties over time.
Carbon steel spring bars are generally not suitable for cryogenic applications due to their reduced toughness and brittleness at extremely low temperatures. Materials like stainless steel or special alloys are preferred for such conditions.
Carbon steel spring rods are available in various sizes, typically ranging from 1/4 inch to several inches in diameter, with lengths varying based on application requirements. Custom sizes can be manufactured to meet specific load, stress, or design needs.
You’ll find Carbon Steel Spring Bars and Rods widely utilized across the automotive, machinery, aerospace, and industrial equipment sectors, thanks to their exceptional mechanical strength and spring performance. They are perfect for crafting suspension components, mechanical springs, shafts, fasteners, and load-bearing rods. Moreover, these bars and rods play a crucial role in precision instruments, valves, and industrial machinery, where resistance to repeated stress, impact, and fatigue is essential. With a blend of toughness, elasticity, and wear resistance, they truly stand out in demanding applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
