Mourad Metals, based in Tunis, Tunisia, stands out as a trusted manufacturer and supplier of top-notch INCONEL 600 bars and rods, serving industries that require outstanding performance and durability. With state-of-the-art manufacturing facilities and rigorous quality control measures, the company guarantees products that align with international standards and meet client needs. The INCONEL 600 bars and rods from Mourad Metals are celebrated for their remarkable resistance to high temperatures, oxidation, and corrosion. Backed by technical know-how and prompt delivery, Mourad Metals has become a go-to source for nickel alloy solutions in markets around the world.
These INCONEL 600 bars and rods are primarily made up of nickel and chromium, with iron playing a key role as an alloying element, along with carefully controlled amounts of carbon, manganese, silicon, and copper. This solid-solution–strengthened alloy boasts impressive tensile and yield strength, excellent fatigue resistance, and high toughness across a wide temperature range. It maintains stable mechanical properties even at elevated temperatures and performs admirably in cryogenic conditions. Its robust resistance to oxidation, carburization, and chloride-ion stress corrosion cracking ensures a long service life.
Specification : ASTM B 166 / ASME SB 166
Dimensions : ASTM, ASME and API
Size : 5 mm To 500 mm Dia in 100 mm TO 6000 mm Length available with NACE MR 01-75.
Length : 100 mm To 3000 mm Long & Above
Finish : Bright, Polish & Black
Grade : Inconel 600 – UNS N06600
Form : Round, Square, Hex (A/F), Rectangle, Wire (Coil Form), Wire-mesh, Billet, Ingot, Forging Etc.
Our Inconel 600 Round Bars conforms to NACE MR0175/ISO 15156
| Grade | Ni | Cr | Fe | C | Mn | S | Si | Cu |
| Inconel 600 | 72.0 min | 14.0 – 17.0 | 6.0 – 10.0 | 0.15 max | 1.0 max | 0.015 max | 0.5 max | 0.5 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
| Temperature | Coefficient of Expansion | Electrical Resistivity | Thermal Conductivity | Specific Heat | |||||
|---|---|---|---|---|---|---|---|---|---|
| °F | °C | 10-6in/in•°F | mm/m•°C | ohm•circ•mil/ft | mL•m | Btu•in/ft2•h•°F | W/m•°C | Btu/lb•°F | J/kg•°C |
| -250 | -150 | 6 | 10.9 | – | – | 86 | 12.5 | 0.073 | 310 |
| -200 | -100 | 6.3 | 11.7 | – | – | 89 | 13.1 | 0.079 | 352 |
| -100 | -50 | 6.7 | 12.3 | – | – | 93 | 13.6 | 0.09 | 394 |
| 70 | 20 | 5.8 | 10.4 | 620 | 1.03 | 103 | 14.9 | 0.106 | 444 |
| 200 | 100 | 7.4 | 13.3 | 625 | 1.04 | 109 | 15.9 | 0.111 | 465 |
| 400 | 200 | 7.7 | 13.8 | 634 | 1.05 | 121 | 17.3 | 0.116 | 486 |
| 600 | 300 | 7.9 | 14.2 | 644 | 1.07 | 133 | 19 | 0.121 | 502 |
| 800 | 400 | 8.1 | 14.5 | 657 | 1.09 | 145 | 20.5 | 0.126 | 519 |
| 1000 | 500 | 8.4 | 14.9 | 680 | 1.12 | 158 | 22.1 | 0.132 | 536 |
| 1200 | 600 | 8.6 | 15.3 | 680 | 1.13 | 172 | 23.9 | 0.14 | 578 |
| 1400 | 700 | 8.9 | 15.8 | 680 | 1.13 | 186 | 25.7 | 0.145 | 595 |
| 1600 | 800 | 9.1 | 16.1 | 686 | 1.13 | 200 | 27.5 | 0.149 | 611 |
| 1800 | 900 | 9.3 | 16.4 | 698 | 1.15 | – | – | – | 628 |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Inconel 600 | 2.4816 | N06600 | NCF600 | NA 13 | МНЖМц 28-2.5-1.5 | – | NiCr15Fe |
Yes, Inconel 600 bars/rods offer excellent resistance to high temperatures, maintaining strength and oxidation resistance in applications up to 2000°F (1093°C).
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@mouradmetals.com
Yes, Inconel 600 bars/rods exhibit exceptional resistance to oxidation, chlorides, and a wide range of acids, making them ideal for harsh chemical and marine environments.
You’ll find INCONEL 600 bars and rods widely used in applications that face extreme heat and corrosive environments. Common uses include furnace hardware, heat-treatment baskets, thermocouple protection tubes, and equipment for chemical processing. They’re also utilized in aerospace components, nuclear power systems, and heat exchangers, thanks to their thermal stability and corrosion resistance. Additional applications span petrochemical processing, marine engineering, and food-handling equipment, where reliability, cleanliness, and ease of fabrication are essential.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Mourad Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Tunis, Tunisia
