Mourad Metals, based in Tunis, Tunisia, stands out as a dependable manufacturer and supplier of top-notch INCONEL 792 bars and rods, specifically designed for demanding industrial applications. With a solid foundation in metallurgical expertise and cutting-edge production capabilities, the company ensures that its materials meet rigorous international standards. The INCONEL 792 bars and rods from Mourad Metals are celebrated for their remarkable high-temperature strength, resistance to oxidation, and precise dimensions. By prioritizing quality assurance, consistent performance, and a customer-centric approach, Mourad Metals has earned a reputation as a trusted provider of nickel-based superalloy products in global markets.
INCONEL 792 is a nickel-based superalloy that boasts a significant blend of chromium, cobalt, aluminum, titanium, tungsten, and tantalum, along with trace amounts of carbon and boron. This meticulously crafted composition grants it outstanding resistance to oxidation and hot corrosion, even at elevated temperatures. On the mechanical side, INCONEL 792 bars and rods deliver impressive tensile, creep, and stress-rupture strength, coupled with excellent thermal stability. The alloy maintains its hardness and structural integrity even when exposed to temperatures exceeding 900°C for extended periods.
| Specifications | ASTM B116 / ASTM SB116 |
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Size | 5 mm to 500 mm |
| Diameter | 0.1 mm to 100 mm |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Length | 100 mm To 3000 mm Long & Above |
| Form | Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc. |
| Element | Composition (%) |
| Nickel (Ni) | 60.0 – 65.0 |
| Chromium (Cr) | 12.0 – 14.0 |
| Cobalt (Co) | 9.0 – 10.0 |
| Aluminum (Al) | 3.0 – 4.5 |
| Titanium (Ti) | 3.5 – 4.5 |
| Molybdenum (Mo) | 1.5 – 2.5 |
| Tantalum (Ta) | 0.50 – 1.50 |
| Zirconium (Zr) | 0.02 – 0.15 |
| Boron (B) | 0.010 – 0.020 |
| Carbon (C) | 0.12 – 0.20 |
| Silicon (Si) | ≤ 0.50 |
| Manganese (Mn) | ≤ 0.50 |
| Iron (Fe) | ≤ 3.0 |
| Property | Value |
| Tensile Strength | 1000 – 1400 MPa |
| Yield Strength (0.2%) | 800 – 1100 MPa |
| Elongation | 5 – 15% |
| Hardness | 350 – 450 HB |
| Impact Strength | Good at elevated temperatures |
| Property | Value |
| Density | 8.25 g/cm³ |
| Melting Range | 1260 – 1340°C |
| Thermal Conductivity | 11.2 W/m·K at 20°C |
| Specific Heat Capacity | 0.410 J/g·K at 20°C |
| Electrical Resistivity | 1.22 μΩ·m at 20°C |
| Coefficient of Thermal Expansion | 13.3 x 10⁻⁶ /°C (20-1000°C) |
Yes, Inconel 792 bars and rods are designed for high-temperature applications, providing excellent strength, oxidation resistance, and thermal stability, making them ideal for extreme heat environments.
Yes, Inconel 792 bars and rods are recyclable. Their high nickel and chromium content allows them to be efficiently reused in various industries, reducing waste and promoting sustainability.
Inconel 792 bars and rods generally do not require additional corrosion protection coatings due to their inherent resistance to oxidation and corrosion, especially in high-temperature and harsh environments.
These INCONEL 792 bars and rods find extensive use in applications that demand exceptional performance in extreme thermal and mechanical conditions. They are commonly utilized in gas turbine components, including blades, vanes, discs, shafts, and fasteners, particularly in the aerospace and power generation sectors. Additionally, they are employed in industrial turbines, heat treatment fixtures, and components that face continuous high temperatures and cyclic thermal loads. In the energy and heavy engineering industries, INCONEL 792 is favored for its long service life, reliability, and impressive resistance to oxidation and thermal fatigue.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Mourad Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Tunis, Tunisia
