Mourad Metals is a well-respected manufacturer and supplier located in Tunis, Tunisia, specializing in high-quality Stainless Steel 317 Square Bars and Rods for a variety of industrial uses. With state-of-the-art manufacturing facilities and rigorous quality control measures, the company guarantees products that align with international standards and meet client expectations. The Stainless Steel 317 Square Bars and Rods from Mourad Metals are celebrated for their outstanding corrosion resistance, particularly in chloride and acidic environments, as well as their impressive mechanical performance. By focusing on precision, durability, and prompt delivery, Mourad Metals has earned a solid reputation as a trustworthy source of stainless steel solutions for both local and global markets.
Stainless Steel 317 Square Bars and Rods are a type of austenitic stainless steel that boasts high levels of chromium, nickel, and molybdenum. This unique composition grants them remarkable resistance to pitting, crevice corrosion, and stress corrosion cracking, even in harsh environments. On the mechanical side, these bars and rods deliver excellent tensile strength, high ductility, and solid toughness. They maintain their structural integrity when exposed to corrosive substances and moderate temperatures for extended periods. Additionally, they offer good weldability and formability, making them ideal for challenging chemical and industrial applications.
Stainless Steel 317 Square Bars Specification :
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A582, A276, A564, ASTM A484, 484M
Surface : hrap, hot rolled pickled or sand blasting finished, cold drawn, polished, hairline
Size : Tolerance: H8, H9, H10, H11, H12, H13K9, K10, K11, K12
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 317 | 0.08 max. | 18.0 – 20.0 | 2.00 max. | 11.0 – 14.0 | 0.045 max. | 0.03 max. | 1.00 max. |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi ” 75000, MPa ” 515 | Psi ” 30000, MPa ” 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 317 | 1.4449 | S31700 |
| SQUARES | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.62 | 2.05 |
| 18 | 0.79 | 2.59 |
| 20 | 0.76 | 2.49 |
| 22 | 1.18 | 3.87 |
| 25 | 1.52 | 5.00 |
| 28 | 1.91 | 6.27 |
| 30 | 2.19 | 7.20 |
| 32 | 2.50 | 8.19 |
| 36 | 3.16 | 10.37 |
| 38 | 3.52 | 11.55 |
| 40 | 3.90 | 12.80 |
| 45 | 4.94 | 16.20 |
| 50 | 6.10 | 20.00 |
| 56 | 7.65 | 25.08 |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Yes, Stainless Steel 317 square bars can be welded using conventional welding methods. However, pre-heating and post-weld heat treatment may be required to avoid cracking.
Yes, Stainless Steel 317 square rods can be heat-treated, typically through solution annealing. However, they are not hardenable by heat treatment like some other stainless steels.
Stainless Steel 317 Square Bars offer excellent corrosion resistance, particularly against chlorides and acids, along with high strength and durability. They are widely used in chemical, petrochemical, and food processing industries.
Stainless Steel 317 Square Bars and Rods find extensive use in industries that demand exceptional corrosion resistance and durability. Common applications include equipment for chemical processing, marine components, pharmaceutical machinery, and systems for oil and gas processing. They are also utilized in petrochemical plants, desalination facilities, and heat exchangers. Thanks to their superior resistance to chlorides and acidic conditions, these stainless steel products are a go-to choice for many demanding environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
