Mourad Metals is a trusted manufacturer and supplier of Titanium Grade 11 Forgings, proudly based in Tunis, Tunisia. They cater to a wide range of global industries with their precision-engineered products. With state-of-the-art forging facilities and rigorous quality control measures, the company provides Titanium Grade 11 forgings that boast impressive corrosion resistance and reliable mechanical performance. Mourad Metals also offers customized sizes and specifications, all while adhering to international standards to guarantee durability, dimensional accuracy, and prompt delivery. Their strong technical know-how and customer-centric approach make them a go-to partner for projects that demand high-quality, corrosion-resistant titanium forgings.
Titanium Grade 11 is a commercially pure titanium alloy that includes a small amount of palladium, usually between 0.12% and 0.25%, to boost its corrosion resistance. The rest is primarily titanium, along with carefully controlled levels of oxygen, iron, carbon, nitrogen, and hydrogen. Titanium Gr 11 forgings are known for their good tensile and yield strength, excellent ductility, and remarkable resistance to pitting, crevice corrosion, and harsh acidic environments. They also offer good weldability, formability, and consistent performance even in tough service conditions.
| Specifications | ASTM B381, ASME SB381 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | N | O | H | Ti | Fe | Al | Pd |
| Titanium Gr 11 | 08 max | 03 max | 25 max | 015 max | Bal | 0.30 max | – | 12 – .25 |
| Grade | Tensile Strength min | Yield Strength (0.2 % Offset) | Elongation | Reduction of Area | ||
| ksi | Mpa | ksi | Mpa | min % | min % | |
| 11 | 35 | 240 | 25 | 170 | 24 | 30 |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 11 | 3.7225 | R52550 |
Yes, Titanium Gr 11 forgings are highly corrosion-resistant, especially to oxidizing environments and seawater. This makes them ideal for applications in industries like aerospace, marine, and chemical processing, ensuring long-lasting durability.
Titanium Gr 11 forgings are commonly used in industries such as aerospace, marine, chemical processing, medical, and power generation. Their strength, corrosion resistance, and high-performance capabilities make them ideal for demanding applications.
Yes, Titanium Gr 11 forgings can be customized for specific applications, offering tailored sizes, shapes, and properties to meet unique industry requirements, ensuring optimal performance and reliability in demanding environments.
These Titanium Gr 11 Forgings find extensive use in the chemical processing, petrochemical, and marine industries, where resistance to aggressive media is essential. Common applications include heat exchangers, condensers, pressure vessels, reactors, piping components, and desalination systems. They are also well-suited for offshore structures and oil and gas equipment that face chloride-rich and sour environments. With their blend of corrosion resistance, strength, and long service life, they are perfect for critical industrial and marine applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
