Mourad Metals is a reputable manufacturer and supplier of Titanium Grade 5 Forgings, proudly based in Tunis, Tunisia. They specialize in delivering precision-engineered solutions to industries around the globe. With a strong commitment to quality, consistency, and adherence to international standards, the company produces high-performance titanium forgings that are specifically designed for demanding applications. Titanium Grade 5, or Ti-6Al-4V, is one of the most popular titanium alloys, celebrated for its remarkable strength-to-weight ratio and resistance to corrosion. Mourad Metals utilizes advanced forging techniques, rigorous quality control, and deep technical expertise to provide reliable, dimensionally accurate forgings that meet the specifications of customers in the aerospace, industrial, and engineering sectors worldwide.
Titanium Grade 5 Forgings are primarily made of titanium, alloyed with about 6% aluminum and 4% vanadium, resulting in a well-balanced alpha-beta alloy structure. This unique composition offers excellent mechanical strength, high fatigue resistance, and impressive fracture toughness. Compared to commercially pure titanium, this alloy boasts superior tensile and yield strength while keeping a relatively low density. Additionally, Titanium Grade 5 forgings demonstrate good creep resistance at elevated temperatures and outstanding corrosion resistance in marine, chemical, and oxidizing environments, making them ideal for both structural and high-stress applications.
| Specifications | ASTM B381, ASME SB381 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade5 | 90 min | – | 0.25 max | – | – | 0.2 max | 6 min | 4 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium Gr. 5 | 4.43 g/cm3 | 1632 °C (2970 °F) | Psi – 138000 , MPa – 950 | Psi – 128000 , MPa – 880 | 14 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 5 | 3.7165 | R56400 |
Durability of Titanium Grade 5 forgings is ensured by proper heat treatment, controlled forging process, precise die design, alloy composition, and maintaining optimal surface finish, enhancing strength, corrosion resistance, and fatigue resistance.
Titanium Gr 5 forgings are commonly used in aerospace, automotive, medical, marine, and defense industries, providing high strength, corrosion resistance, and lightweight properties for critical components and high-performance applications.
Closed-die forging in Titanium Gr 5 production involves shaping titanium by compressing it between two shaped dies, ensuring precise dimensions, high strength, and improved material properties for demanding applications.
Titanium Grade 5 Forgings are primarily made of titanium, alloyed with about 6% aluminum and 4% vanadium, resulting in a well-balanced alpha-beta alloy structure. This unique composition offers excellent mechanical strength, high fatigue resistance, and impressive fracture toughness. Compared to commercially pure titanium, this alloy boasts superior tensile and yield strength while keeping a relatively low density. Additionally, Titanium Grade 5 forgings demonstrate good creep resistance at elevated temperatures and outstanding corrosion resistance in marine, chemical, and oxidizing environments, making them ideal for both structural and high-stress applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
