Mourad Metals is a trusted manufacturer and supplier located in Tunis, Tunisia, dedicated to delivering top-notch aluminium products across various industrial sectors. The company has carved a niche in Aluminium 2017 Bars and Rods, ensuring that their materials adhere to international quality standards and meet precise engineering specifications. With state-of-the-art manufacturing facilities, rigorous quality control measures, and a team of seasoned technical experts, Mourad Metals caters to industries like aerospace, automotive, marine, and general engineering. Their commitment to performance, reliability, and on-time delivery has established them as a go-to partner in both regional and global markets.
Aluminium 2017 is a heat-treatable aluminium-copper alloy, primarily composed of copper, with magnesium and manganese as additional elements. It boasts impressive mechanical strength, outstanding machinability, and dependable fatigue resistance. The Aluminium 2017 Bars and Rods offer moderate corrosion resistance and excel under mechanical stress. This alloy is particularly noted for its favorable response to heat treatment, providing a well-rounded mix of strength, toughness, and dimensional stability, making it perfect for precision-engineered components.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Grade | Al | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Others Each | Other Total |
| 2017 | Rem | 0.20-0.8 | 0.7 max | 3.5-4.5 | 0.40-1.0 | 0.40-0.8 | 0.10 max | 0.25 max | 0.15 max | 0.05 max | 0.15 max |
| Material | Condition | Tensile Strength (N/mm²) min | Yield Strength | Elongation in 4D % | ||
| ksi | Mpa | ksi | Mpa | |||
| 2017 | 2017-T4 Bar | 55 | 379 | 32 | 221 | 12 |
| STANDARD | UNS | WERKSTOFF NR. |
| Aluminium 2017 | A92017 | 3.1325 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 2017 can be welded, but it requires careful control due to its high strength and susceptibility to cracking. Specialized welding techniques like TIG or MIG are recommended.
To maintain Aluminium 2017, regularly clean with mild detergent and water, avoid abrasive materials, store in a dry environment, and prevent exposure to corrosive substances to preserve its strength and appearance.
Aluminium 2017 rods are typically sized by diameter and length. Common diameters range from 1/8 inch to several inches, while lengths can vary from a few feet to custom sizes based on needs.
You’ll find Aluminium 2017 Bars and Rods in a variety of applications that demand good strength and machinability. They’re commonly used in aerospace fittings, automotive components, fasteners, gears, shafts, and precision mechanical parts. Additionally, this alloy is well-suited for structural elements, machinery parts, and tooling designed for moderate-load scenarios. Thanks to its reliable mechanical performance and ease of machining, Aluminium 2017 is an excellent choice for general engineering, transportation, and industrial applications that require both durability and precision.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
