Mourad Metals is a reputable manufacturer and supplier of top-notch non-ferrous metals, proudly based in Tunis, Tunisia. They cater to a variety of sectors, including aerospace, automotive, electrical, and industrial markets around the globe. One of their standout products is the **Aluminium 6101 T6 Bars and Rods**, crafted with precision to guarantee uniform dimensions, a superb surface finish, and reliable mechanical properties. Thanks to their state-of-the-art production facilities and rigorous quality control measures, Mourad Metals ensures that their aluminium products comply with international standards. Their technical know-how, customer-centric approach, and dependable logistics make them a go-to choice for corrosion-resistant, lightweight, and high-strength aluminium solutions.
The Aluminium 6101 T6 Bars and Rods are created from an aluminium-magnesium-silicon alloy that undergoes heat treatment to achieve the T6 temper. This unique blend offers impressive mechanical strength, solid corrosion resistance, high electrical conductivity, and exceptional thermal conductivity. In terms of mechanics, 6101 T6 bars boast good tensile and yield strength, high hardness, and remarkable fatigue resistance, making them perfect for demanding structural and electrical applications.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Aluminum, Al | Magnesium, Mg | Silicon, Si |
|---|---|---|
| 98.9 | 0.60 | 0.50 |
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength | 97 MPa | 14069 psi |
| Yield strength | 76 MPa | 11023 psi |
| Elastic modulus | 70-80 GPa | 10153-11603 ksi |
| Poisson’s ratio | 0.33 | 0.33 |
| INDIA | U.S.A. | BRITAIN | CANADA | GERMANY | RUSSIA | I.S.O. | FRENCH | NORTH AMERICA | DIN Nos. | |
|---|---|---|---|---|---|---|---|---|---|---|
| New IS | Old IS | (A.A.) | (B.S.) | (DIN) | – | – | – | UNS | DIN | |
| 63401 | 91E | 6101 | 91E | D50S | E.Al.Mg.Si 0.5 | – | – | – | A96101 | 3.2315 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 6101 T6 bars are recyclable. Aluminium, including alloys like 6101 T6, can be recycled indefinitely without losing its properties, making it an environmentally friendly material for sustainable manufacturing.
Yes, Aluminium 6101 T6 rods can be customized in size and length to meet specific requirements. Manufacturers often offer various diameters, lengths, and finishes, allowing the rods to be tailored for different applications.
To select the right Aluminium 6101 T6 bar or rod, consider factors like strength requirements, electrical conductivity, corrosion resistance, weight, and intended application (e.g., electrical, structural, aerospace, or industrial use).
These Aluminium 6101 T6 Bars and Rods find their way into various industries, including electrical, construction, and transportation. Common uses include busbars, electrical connectors, heat sinks, structural components, and automotive parts. They’re also utilized in aerospace, power distribution systems, and general fabrication where a mix of high strength, corrosion resistance, and lightweight characteristics is crucial. Their adaptability and performance make them a fantastic choice for both electrical and mechanical engineering projects.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
