Mourad Metals is a trusted manufacturer and supplier of Aluminium 3003 Bars and Rods, proudly based in Tunis, Tunisia. The company is dedicated to providing top-notch aluminium products that adhere to international standards, catering to a diverse array of industries such as construction, transportation, and manufacturing. With state-of-the-art production facilities and rigorous quality control measures, Mourad Metals ensures that their Aluminium 3003 Bars and Rods are recognized for their outstanding corrosion resistance, durability, and reliable performance—making them perfect for applications that demand long-lasting materials.
Aluminium 3003 is an aluminium-manganese alloy that contains about 1.0–1.5% manganese, which boosts its strength while still offering excellent corrosion resistance. In terms of mechanics, Aluminium 3003 bars and rods showcase moderate strength, good ductility, and exceptional workability. This alloy is known for its impressive resistance to atmospheric corrosion, good weldability, and ease of machining. The typical tensile strength falls between 110 to 145 MPa, depending on the temper and processing conditions.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Grade | Al | Cr | Cu | Fe | Mg | Mn | Other Total | Si | Ti | Zn |
| min. | Remainder | – | 0.05 to 0.20% | 0.7% | – | 1.0 to 1.5% | 0.15% | 0.6% | – | 0.10% |
| Properties | Metric | Imperial |
| Tensile strength | 130 MPa | 18855 psi |
| Yield strength | 125 MPa | 18130 psi |
| Shear strength | 83 MPa | 12039 psi |
| Fatigue strength | 55 MPa | 7977 psi |
| Elastic modulus | 70-80 GPa | 10153-11603 ksi |
| Poisson’s ratio | 0.33 | 0.33 |
| Elongation | 10% | 10% |
| Hardness | 35 | 35 |
| STANDARD | UNS | WERKSTOFF NR. |
| Aluminium 3003 | A93003 | 3.0517 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 3003 bars can be welded using standard welding techniques, such as TIG or MIG welding. Its excellent corrosion resistance and weldability make it ideal for various applications.
Yes, Aluminium 3003 bars and rods are suitable for hygienic and sanitary applications due to their corrosion resistance, lightweight nature, and excellent ability to withstand moisture and chemical exposure.
Aluminium 3003 bars have excellent corrosion resistance due to their manganese content, making them highly resistant to rust and chemical exposure in most environments, including marine and industrial settings.
Aluminium 3003 Bars and Rods find their way into various applications, including roofing and siding, chemical tanks, heat exchangers, and automotive trim components. They are also utilized in marine environments, architectural structures, and general fabrication where corrosion resistance and ease of forming are crucial. Thanks to their durability, versatility, and excellent corrosion resistance, Aluminium 3003 bars and rods are a fantastic choice for both indoor and outdoor uses.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
